瑞康5032mm晶振,QESM05.1.20.HQ.10.12/25.000MHZ,25MHZ

瑞康5032mm晶振,QESM05.1.20.HQ.10.12/25.000MHZ,25MHZ，尺寸5.0x3.2mm，频率25MHZ，欧美进口晶振，Rakon石英振动子，无源贴片晶振，石英贴片晶振，5032mm轻型晶振，无源石英晶振，轻薄型晶振，25MHZ贴片晶振，石英晶体谐振器，智能手机晶振，测试设备晶振，智能穿戴晶振，视听设备晶振，以太网晶振，小型设备晶振，高性能晶振，高品质晶振，低损耗晶振，低功耗晶振，低耗能晶振，具有高品质低耗能的特点。

晶振晶体产品比较适合用于智能手机，测试设备，智能穿戴，视听设备，以太网，小型设备等应用。瑞康5032mm晶振,QESM05.1.20.HQ.10.12/25.000MHZ,25MHZ.

瑞康5032mm晶振,QESM05.1.20.HQ.10.12/25.000MHZ,25MHZ参数表

Parameter Nominal frequency (Fn)

Min.

Typ. 25

Max.

Unit MHz

Test condition / Description

Calibration tolerance

±10 to ±50

ppm

Frequency at 25°C ± 2°C and specified load capacitance

Reflow shift

±1

ppm

Frequency shift after reflow with 4 hours settling at 25°C

Operating temperature range

-20 to +70

-40 to +85

°C

Refer to ordering information

Storage temperature range

-55

+125

°C

Frequency stability over temperature

±10 to ±50

ppm

Referenced to frequency reading at 25°C and the specified load capacitance

Long-term stability (Aging)

±2

ppm

Frequency drift over 1 year at 25°C

Shunt capacitance (CO)

7.0

pF

Load capacitance (CL)

8

30

pF

Refer to ordering information

Drive level

10

100

300

µW

Equivalent series resistance (ESR) 8.000 to 9.999MHz 10.000 to 13.999MHz 14.000 to 19.999MHz 20.000 to 29.999MHz 30.000 to 47.999Mhz 48.000 to 80.000Mhz

100 80 60 50 40 70

a

Mode of vibration: Fundamental (AT-cut) Fundamental (AT-cut) Fundamental (AT-cut) Fundamental (AT-cut) Fundamental (AT-cut) 3rdOvertone (AT-cut)

Insulation resistance (IR)

500

Ma

100 V ±15 V at 25°C

瑞康5032mm晶振,QESM05.1.20.HQ.10.12/25.000MHZ,25MHZ尺寸图

瑞康5032mm晶振,QESM05.1.20.HQ.10.12/25.000MHZ,25MHZ

SMD晶体产品特点:

尺寸5.0x3.2mm

频率范围8~80MHZ

低损耗高性能

符合RoHS标准且无铅
