遥遥领先麦特伦皮M3x5x系列VCXO晶振

2023-10-08 14:55:34

M3x5x系列

遥遥领先麦特伦皮M3x5x系列VCXO晶振

M3x5x Series 3.2 x 5.0 mm High Frequency VCXO

MtronPTI today introduced the M305x series small form factor high performance Voltage Controlled Crystal Oscillator (VCXO). The M305x series VCXO delivers jitter performance as low as 130fs at 622.08MHz across the entire operating temperature. This outstanding jitter performance supports demanding applications including data center interconnect, broadcast video, and test and measurement. The M305x series VCXO is available with single, dual, and quad output formats, a output frequencies up to 2100MHz and is in an industry standard 3.2 x 5.0 mm package, making it ideal for space constrained designs. The M305x series VCXO further expands MtronPTI’s industry leading portfolio of high performance VCXOs.
MtronPTI offers a broad line of precision crystal resonators, oscillators, filters, and Integrated Microwave Assembly solutions.
MtronPTI is an ISO 9001:2015 and AS9100 Rev. D certified organization.

Features:
3.2 x 5.0mm ceramic package
Frequency selection function: Single, Dual, or Quad
Operating voltage 3.3V, 2.5V or 1.8V
Low jitter: Typ. 130fs rms @622.08MHz
Supports a wide frequency range: 15MHz to 2100MHz
Operating temperature range up to -45 °C to +85 °C
Output formats: CMOS, LVPECL, LVDS, CML or HCSL
Applications:
Test and Measurement
Industrial
Optical Transmission

M3x5x系列-1

遥遥领先麦特伦皮M3x5x系列VCXO晶振
M3x5x系列3.2x5.0毫米高频VCXO
MtronPTI麦特伦皮晶振公司今天新推出了M305x系列,小尺寸高性能压控晶体振荡器(VCXO)。M305x系列VCXO在整个工作温度范围内以622.08MHz的频率提供低至130fs的抖动性能。这种出色的抖动性能支持要求苛刻的应用,包括数据中心互连、广播视频以及测试和测量。M305x系列VCXO提供单通道、双通道和四通道输出格式,输出频率高达2100MHz,采用行业标准3.2x5.0mm封装,六脚贴片晶振,石英晶振,石英晶体振荡器,具有超小型,轻薄型,低抖动,低功耗,低电源电压,低损耗,低耗能,低电平等特点,非常适合空间受限的设计。M305x系列VCXO进一步扩展了MtronPTI业界领先的高性能VCXO产品组合。
MtronPTI麦特伦皮晶振提供各种精密晶体谐振器、晶体振荡器、滤波器和集成微波组件解决方案。
MtronPTI是ISO 9001:2015和AS9100 Rev. D认证组织。
M305x系列产品特点:
小体积尺寸:3.2x5.0mm毫米陶瓷封装压控晶振
频率选择功能:单通道、双通道或四通道
工作电压:3.3V、2.5V或1.8V
低抖动:典型值:622.08MHz时130fs rms
支持宽频率范围:15MHz至2100MHz
工作温度范围高达:-45°C至+85°C
输出格式:CMOS、LVPECL、LVDS、CML或HCSL差分晶振

应用:测试,产业的,光传输
