M1004S050 12.288000|12.288MHz|HC-49S|50PPM|-40~85℃|MtronPTI，贴片石英晶振，ATS-49晶体,ATS-49 00.0000 MHz（客户指定）*ATS-49-R00.0000MHz（符合RoHS和客户指定的频率）M1004Sxxx-规格书请联系我们。
M1004S050 12.288000|12.288MHz|HC-49S|50PPM|-40~85℃|MtronPTI
| 参数 | 符号 | 最小值 | 典型的 | 最大值 | 单位 | 备注 |
| 频率范围 | F | 3.579545 | 72 | MHz | ||
| 频率公差 | F/F | -30 | +30 | ppm | ||
| 频率稳定度 | AF/F | -50 | +50 | ppm | See Note 1 | |
| 工作温度 | TA | - 10 | +70 | °C | ||
| 储存温度 | TS | -55 | +125 | °C | ||
| 老化 | ±5 | ±5 | ||||
| 负载电容 |
 L
|
18 | pF | See Note 2 | ||
| 并联电容 | CO | 7 | pF | |||
| ESR |
 See ESR Table
|
|||||
| 驱动电平 | DL | 25 | 100 | 500 | W | |
| 绝缘电阻 | IR | 500 | MOhms | |||
| 机械震动 | MIL-STD-202, Method 213, C (100 g’s) | |||||
| 摆动 | MIL-STD-202, Method 201 & 204 (10 g’s from 10-2000 Hz) | |||||
| 热处理工业周期 | MIL-STD-883, Method 1010, B (-55°C to 125°C, 15 min dwell, 10 cycles) | |||||
| 密封性 | MIL-STD-202, Method 112 (must meet 1 x 10-8) | |||||
| 可焊性 | Per EIAJ-STD-002 | |||||
| 波焊条件 | +260°C for 10 secs. Max. | |||||
M1004S050 12.288000|12.288MHz|HC-49S|50PPM|-40~85℃|MtronPTI
| MTRONPTI原厂编码 | 型号 | 频率公差 | 频率(MHz) | 老化 | 封装 | 负载 | 温度范围 |
| M1001S025-R 3.686400 | ATSM-49-R | ±50 ppm | 3.6864 | ±5 ppm | HC-49S-SMD | 18 pF | -40?C to +85?C |
| M1001S066 25.000000 | ATSM-49-R | ±50 ppm | 25 | ±5 ppm | HC-49S-SMD | 12 pF | -10?C to +70?C |
| M1001S096 24.000000 | ATSM-49-R | ±50 ppm | 24 | ±5 ppm | HC-49S-SMD | 12 pF | -40?C to +125?C |
| M1001S097 30.000000 | ATSM-49-R | ±50 ppm | 30 | ±5 ppm | HC-49S-SMD | 12 pF | -40?C to +125?C |
| M1001S175-R 4.000000 | ATSM-49-R | ±10 ppm | 4 | ±5 ppm | HC-49S-SMD | 20 pF | 0?C to +70?C |
| M1001S182 25.000000 | ATSM-49-R | ±50 ppm | 25 | ±5 ppm | HC-49S-SMD | 18 pF | -40?C to +85?C |
| M1001S214 8.000000 | ATSM-49-R | ±50 ppm | 8 | ±5 ppm | HC-49S-SMD | 18 pF | -40?C to +85?C |
| M1001S258 10.000000 | ATSM-49-R | ±50 ppm | 10 | ±5 ppm | HC-49S-SMD | 18 pF | -40?C to +125?C |
| M1001S286 26.000000 | ATSM-49-R | ±50 ppm | 26 | ±3 ppm | HC-49S-SMD | 3 pF | -20?C to +75?C |
| M1001S328 26.000000 | ATSM-49-R | ±15 ppm | 26 | ±3 ppm | HC-49S-SMD | 9 pF | -40?C to +85?C |
| M1001S445 50.000000 | ATSM-49-R | ±20 ppm | 50 | ±3 ppm | HC-49S-SMD | 10 pF | -40?C to +85?C |
| M1001S448 8.000000 | ATSM-49-R | ±50 ppm | 8 | ±5 ppm | HC-49S-SMD | 18 pF | -55?C to +105?C |
| M1001S483 4.194304 | ATSM-49-R | ±50 ppm | 4.1943 | ±5 ppm | HC-49S-SMD | 12 pF | -10?C to +70?C |
| M1001S554 25.000000 | ATSM-49-R | ±50 ppm | 25 | ±5 ppm | HC-49S-SMD | 18 pF | -20?C to +70?C |
| M1001S559 14.463660 | ATSM-49-R | ±30 ppm | 14.4637 | NS | HC-49S-SMD | 10 pF | -40?C to +105?C |
| M1001S599 24.576000 | ATSM-49-R | ±100 ppm | 24.576 | ±3 ppm | HC-49S-SMD | 8 pF | -55?C to +125?C |
| M1001S600 16.777216 | ATSM-49-R | ±50 ppm | 16.7772 | ±5 ppm | HC-49S-SMD | 15 pF | -40?C to +85?C |
| M1001S602 8.000000 | ATSM-49-R | ±50 ppm, ±100 ppm | 8 | ±5 ppm | HC-49S-SMD | 20 pF | 0?C to +70?C |
| M1001S609 4.000000 | ATSM-49-R | ±100 ppm | 4 | ±3 ppm | HC-49S-SMD | 18 pF | -40?C to +125?C |
| M1002S286 57.770833 | HC-49UN | ±10 ppm | 57.7708 | ±1 ppm | HC-49U | Series Resonant | -20?C to +70?C |
| M1004S050 12.288000 | ATS-49 | ±50 ppm | 12.288 | ±5 ppm | HC-49S | 15 pF | -40?C to +85?C |
| M1004S051 20.000000 | ATS-49 | ±50 ppm | 20 | ±5 ppm | HC-49S | 15 pF | -40?C to +85?C |
| M1004S156 24.000000 | ATS-49 | ±50 ppm | 24 | ±5 ppm | HC-49S | 5 pF | -40?C to +70?C |
| M1006S028 16.384000 | HC-49UN | ±30 ppm | 16.384 | ±5 ppm | HC-49U-SMD | 14 pF | -40?C to +85?C |
| M1006S034 20.000000 | HC-49UN | ±30 ppm | 20 | ±5 ppm | HC-49U-SMD | 14 pF | -10?C to +70?C |
| M1006S046 1.843200 | HC-49UN | ±50 ppm | 1.8432 | ±5 ppm | HC-49U-SMD | 22 pF | -40?C to +85?C |
| M1006S049 3.686400 | HC-49UN | ±100 ppm | 3.6864 | ±3 ppm | HC-49U-SMD | 20 pF | -40?C to +85?C |
| M1252S039 16.000000 | M1252 | ±30 ppm | 16 | ±3 ppm | 2.0 x 2.5 mm | 10 pF | -10?C to +60?C |
| M1252S040 26.000000 | M1252 | ±10 ppm | 26 | ±3 ppm | 2.0 x 2.5 mm | 15 pF | -10?C to +60?C |
| M1252S043 32.000000 | M1252 | ±20 ppm | 32 | ±3 ppm | 2.5 x 2.0 mm | 10 pF | -40?C to +85?C |
| M1252S049 16.000000 | M1252 | ±25 ppm | 16 | ±3 ppm | 2.5 x 2.0 mm | 8 pF | -40?C to +85?C |
