Micro Crystal,CM8V-T1A-100.000kHz-9pF-100PPM-TA-QC,-40~85℃,2012,瑞士微晶晶振公司，CM8V-T1A是一个低频SMT石英晶体单元，它包含了一个音叉石英晶体谐振器。它在真空下工作，在一个密封的陶瓷包装与金属盖子。应用物联网计量工业自动化体积超小，外形较低，重量较轻(4.6毫克）。杰出的密封与金锡预制件。采用密封性密封来保证，稳定性高，老化程度低。可用于更扩展的工作温度范围。高冲击和抗振动能力。100%无铅，rohs兼容。根据AEC-Q200提供的汽车资格认证。物联网计量，工业汽车医疗保健，可穿戴设备，便携式设备。
Micro Crystal,CM8V-T1A-100.000kHz-9pF-100PPM-TA-QC,-40~85℃,2012
|
标称频率 32.768 kHz / 100.000 kHz |
FL | 32.768 | kHz |
| 负载电容 | CL | 4.0 / 6.0 / 7.0 / 9.0 / 12.5 | pF |
| 频率容差 | ΔF/F | ±20 | ppm |
| ΔF/F | ± 100 | ppm | |
| 串联电阻最大值 | RS | 55 / 75 |
 Ω
|
| 运动电容型 | C1 | 4.0 | fF |
| 静态电容型 | C0 | 1.2 | pF |
| 驱动电平最大值 | P | 0.5 | μW |
| 绝缘电阻 | Ri | 500 | MΩ |
| 老化 | ΔF/F | ±3 | ppm |
| 转换温度 | T0 | 25 ±5 | °C |
| 频率与温度 | ΔF/F0 | –0.035 ppm/°C² (T - T0)2± 10% | ppm |
Micro Crystal,CM8V-T1A-100.000kHz-9pF-100PPM-TA-QC,-40~85℃,2012
| 微晶原厂编码 | 制造商 | 描述 | 频率 | 容差 |
| CC5V-T1A-32.768kHz-12.5pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CC5V-T1A-32.768kHz-9pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CC5V-T1A-32.768kHz-7pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 7.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CC5V-T1A-32.768kHz-12.5pF-20PPM-TB-QC | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM -40/+125C | 32.768 kHz | 20 PPM |
| CC5V-T1A-32.768kHz-7pF-20PPM-TB-QC | 微晶晶振 | 晶体 32.768 kHz 7.0 pF +/-20 PPM -40/+125C | 32.768 kHz | 20 PPM |
| CC5V-T1A-32.768kHz-6pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 6.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-9pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768k-12.5pF-20PPM-TB-QA | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200 | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768k-9pF-20PPM-TB-QA | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-20 PPM -40/+125C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-12.5pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-7pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 7.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-6pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 6.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-12.5pF-20PPM-TB-QC | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM -40/+125C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-7pF-20PPM-TB-QC | 微晶晶振 | 晶体 32.768 kHz 7.0 pF +/-20 PPM -40/+125C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768k-12.5pF-20PPM-TA-QA | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM AEC-Q200 | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-9pF-20PPM-TB-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-20 PPM -40/+125C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-7pF-100PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 7.0 pF +/-100 PPM -40/+85C | 32.768 kHz | 100 PPM |
| CM8V-T1A-32.768kHz-12.5pF-20PPM-TC-QC | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-20 PPM -55/+125C | 32.768 kHz | 20 PPM |
| CM8V-T1A-32.768kHz-9pF-100PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-100 PPM -40/+85C | 32.768 kHz | 100 PPM |
| CM8V-T1A-100.000kHz-9pF-100PPM-TA-QC | 微晶晶振 | 晶体 100.000 kHz 9.0 pF +/-100 PPM -40/+85C | 100 kHz | 100 PPM |
