Micro Crystal|CC1V-T1A-307.20kHz-4pF-100PPM-TA-QC|-40~85℃,瑞士微晶晶振公司，CC1V-T1A是一个低频SMT石英晶体单元，它包含了一个音叉石英晶体谐振器。它在真空下工作，在一个密封的陶瓷包装与陶瓷盖。成熟的产品，适合恶劣的环境。杰出的密封与金锡预制件。采用密封性密封来保证，稳定性高，老化程度低。可用于更扩展的工作温度范围。高冲击和抗振动能力。100%无pb，符合rohs标准。计量,工业,汽车,医疗保健,恶劣环境,消费电子产品。
Micro Crystal|CC1V-T1A-307.20kHz-4pF-100PPM-TA-QC|-40~85℃
| 频率范围 | FL | 10–200 | 201–560 | 561–2'000 | kHz |
| 负载电容 | CL |
9.0 12.5 |
4.0 | 10.0 | pF |
| 频率公差 | ΔF/F | ±20 | ±100 | ±100 | ppm |
| ΔF/F | ±100 | ±250 | ±500 | ppm | |
| 驱动电平最大值 | P | 1.0 | μW | ||
| 绝缘电阻最小值 | Ri | 500 | MΩ | ||
| 老化 | ΔF/F | ±3 | ppm | ||
| 标称频率 | FL | 32.768 | 307.200 | 1'8432 | kHz |
| 串联电阻最大值 | RS | 40 / 60 | 1.4 / 3.5 | 0.12 / 0.4 |
 Ω
|
| 运动电容型 | C1 | 2.0 | 1.6 | 3.8 | fF |
| 静态电容型 | C0 | 1.6 | 2.0 | 1.6 | pF |
| 转换温度 | T0 | 25 ±5 | 32 ±5 | 33 ±5 | °C |
| 频率与温度 | ΔF/F0 | –0.035 ppm/°C² (T - T0)2±10% | ppm | ||
Micro Crystal|CC1V-T1A-307.20kHz-4pF-100PPM-TA-QC|-40~85℃
| 微晶原厂编码 | 制造商 | 描述 | 频率 | 容差 |
| CC1V-T1A-1.8432MHz-10pF-500PPM-TC-QC | 微晶晶振 | 晶体 1.8432 MHz 10.0 pF 500 PPM -55/+125C | 1.8432 MHz | 500 PPM |
| CC1V-T1A-307.20kHz-4pF-100PPM-TC-QC | 微晶晶振 | 晶体 307.200 kHz 4.0 pF 100 PPM -55/+125C | 307.2 kHz | 100 PPM |
| CC1V-T1A-1.8432MHz-10pF-100PPM-TA-QC | 微晶晶振 | 晶体 1.8432 MHz 10.0 pF +/-100 PPM -40/+85C | 1.8432 MHz | 100 PPM |
| CC1V-T1A-1.8432MHz-10pF-100PPM-TC-QC | 微晶晶振 | 晶体 1.8432 MHz 10.0 pF 100 PPM -55/+125C | 1.8432 MHz | 100 PPM |
| CC1V-T1A-32.768kHz-9pF-100PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-100 PPM -40/+85C | 32.768 kHz | 100 PPM |
| CC1V-T1A-32.768kHz-9pF-20PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-20 PPM -40/+85C | 32.768 kHz | 20 PPM |
| CC1V-T1A-1.8432MHz-10pF-500PPM-TA-QC | 微晶晶振 | 晶体 1.8432 MHz 10.0 pF +/-500 PPM -40/+85C | 1.8432 MHz | 500 PPM |
| CC1V-T1A-1.2288MHz-10pF-100PPM-TA-QC | 微晶晶振 | 晶体 1.2288 MHz 10.0 pF +/-100 PPM -40/+85C | 1.2288 MHz | 100 PPM |
| CC1V-T1A-1.2288MHz-10pF-100PPM-TC-QC | 微晶晶振 | 晶体 1.2288 MHz 10.0 pF 100 PPM -55/+125C | 1.2288 MHz | 100 PPM |
| CC1V-T1A-40.000kHz-9pF-30PPM-TC-QC | 微晶晶振 | 晶体 40.000 kHz 9.0 pF +/-30 PPM -55/+125C | 40 kHz | 30 PPM |
| CC1V-T1A-307.20kHz-4pF-100PPM-TA-QC | 微晶晶振 | 晶体 307.200 kHz 4.0 pF +/-100 PPM -40/+85C | 307.2 kHz | 100 PPM |
| CC1V-T1A-32.768kHz-12.5pF-30PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 12.5 pF +/-30 PPM -40/+85C | 32.768 kHz | 30 PPM |
| CC1V-T1A-32.768kHz-9pF-30PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-30 PPM -40/+85C | 32.768 kHz | 30 PPM |
| CC1V-T1A-32.768kHz-9pF-15PPM-TA-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-15 PPM -40/+85C | 32.768 kHz | 15 PPM |
| CC1V-T1A-32.768kHz-9pF-30PPM-TC-QC | 微晶晶振 | 晶体 32.768 kHz 9.0 pF +/-30 PPM -55/+125C | 32.768 kHz | 30 PPM |
| CC1V-T1A-1.000MHz-10pF-100PPM-TA-QC | 微晶晶振 | 晶体 1.000 MHz 10.0 pF +/-100 PPM -40/+85C | 1 MHz | 100 PPM |
| CC1V-T1A-2.000MHz-10pF-100PPM-TA-QC | 微晶晶振 | 晶体 2.000 MHz 10.0 pF +/-100 PPM -40/+85C | 2 MHz | 100 PPM |
| CC1V-T1A-40.000kHz-9pF-30PPM-TA-QC | 微晶晶振 | 晶体 40.000 kHz 9.0 pF +/-30 PPM -40/+85C | 40 kHz | 30 PPM |
