151系列,151-13.000M-SR-05HS-VS,美国Oscilent插件晶体,13MHZ,美国进口晶振,石英插件晶振,无源石英晶振,石英晶体谐振器,水晶振动子,大尺寸晶振,13MHZ无源晶振,尺寸11*5.0mm,频率13MHZ,工作温度-20~+70℃,无铅环保晶振,低老化晶振,低损耗晶振,低耗能晶振,高可靠晶振,高性能晶振,数字电子晶振,蓝牙应用晶振,笔记本电脑晶振,玩具设备晶振.
151系列,151-13.000M-SR-05HS-VS,美国Oscilent插件晶体,13MHZ特点:
行业标准套装,宽频率范围
晶振晶体超薄型，卓越的可靠性/老化
AT Strip”坯料技术,经济高效
RoHs/无铅合规
151系列,151-13.000M-SR-05HS-VS,美国Oscilent插件晶体,13MHZ参数表
| Parameter | Conditions | Characteristics | Units | |||||||||||||||||
| Frequency Range | fO | 13.00 | MHz | |||||||||||||||||
| Frequency Tolerance | Ref @ +25°C | ±30 std. (±5 ~ ±100 avail.) | PPM | |||||||||||||||||
| Temperature Stability | TL | ±50 std. (See Table 2) | PPM | |||||||||||||||||
| Operating Temperature | TOPR | -10 ~ +60 std. (See Table 2) | °C | |||||||||||||||||
| Storage Temperature | TSTG | -55 ~ +125 | °C | |||||||||||||||||
| Resistance | ESR | (See Table 1) | Ohms | |||||||||||||||||
| Mode of Operation | (See Table 1) | |||||||||||||||||||
| Shunt Capacitance | CO | 7.0 max. | pF | |||||||||||||||||
| Load Capacitance | CL | 20 std. (8 ~ 50 and Series avail.) | pF | |||||||||||||||||
| Drive Level | DL | 0.1 ~ 1.0 | mW | |||||||||||||||||
| Aging (First Year) | @ +25°C | ±5.0 | PPM/Y | |||||||||||||||||
| Insulation Resistance | IR | 500 (DC100 ±10V) min. | Mohm | |||||||||||||||||
151系列,151-13.000M-SR-05HS-VS,美国Oscilent插件晶体,13MHZ尺寸图
